Zooz 800 Series Z-Wave Long Range Outdoor Motion Sensor ZSE70 800LR | Motion, Temp, Lux

$35.95 $42.95

| /

Outdoor MultiSensor

PRODUCT HIGHLIGHTS

  •   BETA RELEASE: You may need to updated your firmware in the near future. Your hub may not fully support this device at the time of purchase.
  • Security alerts: Get instant motion reports to your Z-Wave hub whenever movement is detected.
  • More climate data: Monitor temperature outdoors or indoors and use this information to trigger connected devices in your system.
  • Smart lighting: program your Z-Wave outdoor lights to come on when the Zooz sensor reports motion and lux levels below your preferred set point
  • Z-Wave Long Range ready: extend the wireless coverage up to 1300 feet if your hub supports Long Range
  • Power it with 2 CR123A batteries (included) or a 12-24 V AC/DC connection (sold separately)
  • Works as Z-Wave signal repeater when powered with 12-24 V AC/DC (do NOT pair the sensor on USB cable and then switch to batteries)
  • 800 series Z-Wave chip: more range for reliable wireless communication
  • SmartStart and S2 authenticated security
  • Advanced settings to customize your sensor, including the ability to disable reporting for any sensor
  •  CHECK HUB COMPATIBILITY BEFORE BUYING (NOT SUPPORTED BY WINK OR ALARM PANELS)
  • Modern minimal design with a multi-directional mini mounting bracket
  • Extended 5-year warranty (if registered within 30 days of purchase) and lifetime tech support

    NOTE: Z-Wave gateway controller required - sold separately. You need a security enabled controller to take full advantage of the product.

    SPECIFICATIONS

      • Z-Wave Region: US / CA / MX
      • Z-Wave Chip: 800 series
      • Power: 2 CR123A battery (included) / 12-24 V AC/DC (sold separately)
      • Z-Wave Range: Up to 150 feet line of sight (or up to 1300 feet with Long Range enabled)
      • Motion Detection: 30 feet
      • Operating Humidity: 8%- 100% non-condensing
      • Light Sensor Detection Range: 0 – 65535 lux
      • Operating Temperature: 14°F to 122°F (with accuracy of ±2°C)
      • Dimensions: 2.34” x 2.4” x 2.75”
      • Installation: Indoor / Outdoor (IP66 rated)

    RESOURCES

    Zooz 800 Series Z-Wave Long Range Outdoor Motion Sensor ZSE70 800LR Manual (PDF)

    Advanced Settings

    Support Portal

    WORKS WITH

      • Z-Box Hub (recommended for Zooz products)
      • Home Assistant (Z-Wave JS)
      • HomeSeer (with Z-Wave Plus plug-in)
      • Hubitat (with custom driver)
      • SmartThings Hub (with custom lua driver)

    NOTE: If you don't see your Z-Wave controller on the list above, please contact us before you purchase this product.

    GET POWER SUPPLY

    DC:

    Your existing landscape lighting low Voltage power source will work great too!

    Customer Reviews

    Based on 16 reviews
    63%
    (10)
    38%
    (6)
    0%
    (0)
    0%
    (0)
    0%
    (0)
    J
    Jgwok
    Works as Expected

    Fits my needs. Performance is good.

    M
    McGregor
    Long Range makes the difference...

    I replaced 3 Z-Wave devices in my detached garage that just weren't communicating as well as I would have liked. Replacing them with 800LR from Zooz has answered the problems.

    D
    Dave
    Amazing - finally an outdoor motion sensor

    Coming from Insteon which had a true outdoor motion sensor, it took months before this was available in the Zwave word. There's no real outdoor water rated motion sensors for zwave or zigbee. Someone is listening to their customers. Fantastic design, power by battery or 12-24v plug -- yes!! The array of built in sensors and features is fantastic covering simple motion tasks to more complicated automation that can use lux readings. Temperature offsets, how it reports different sensors by change increment or by time. Just amazing, this is one amazing motion multi sensor.

    K
    Kevin Walsh
    Truly waterproof Z-Wave PIR on market, but bummer mounting

    The ZSE70 clearly has waterproofing that the ZSE29 lacked, especially a robust gland for power supply cable if you go power-line. If battery, it utilizes two CR123A batteries instead of one, which I imagine means longer life and/or range. The battery cover has a gasket and requires a satisfying effort to close. I did not test the waterproofing, but it is obviously the best of all home motion sensors I’ve installed in the past 15 years.

    I am miffed that the motion detection range seems to be about the same as the older model, but that's not the big problem.

    Sadly, the ZSE70 mounting is flimsy compared to the ZSE29 and frankly most other products on the market. The tab/channel connecting the device to the wall-mount base is fragile. I purchased four ZSE70 and almost broke the first one when attaching the mount base. The "shoe" part of the mount is very small and easily deforms the "channel" if you do not support the stem when mounting the sensor to the base. I worry that attempting to replace the batteries will result in breaking the shoe/channel mounting of the sensor.

    C
    C.
    Pros and Cons of the new motion sensor

    The new sensor Pro’s:
    • Smaller unit and smaller footprint allows for increased use cases
    • Battery and AC/DC power provides good options
    • Well manageable settings via your hub settings
    Con’s:
    • Adding the AC power supply, as in attaching the DC wires is not easy, You almost need three hands as you need to push the little buttons down, while holding the unit while inserting the wires. Manual is not much help. This should have been better
    • Plastic attachment to the wall mount, the piece that slides in, is fragile. I can see this break easily.
    • Batteries are not standard AAA like the previous ZOOS sensor, so no rechargeables.

    All in all, a good alternative, albeit not cheap. We’ll see how long the 10 or so I have will last and how they perform.
    In short, if you are looking for outdoor motion sensors Z-wave, these are a good choice.
